Model

H2 1530/1540/2040/2060

Working area

1500x3000mm/1500x4000mm/2000x4000mm/2000x6000mm

Laser power

1500W/2000W/3000W/6000W

Laser source

Raycus/BWT

Laser head

Raytool (autofocus)

Cooling type

Hanli / S&A Chiller

Control system

Cypcut 2000 control system

Reducer

Japan SHIMPO/Japan Shimpo VRT flanges output

Drive system

YASKAWA servor motor and driver

Transmission

Taiwan high precision rack APEX /YCC M2.0

Guiding rail

Dust proofing and waterproofing design

X,Y axis with plastic dustproof

Engraving speed

0-30000mm/min

Laser out-put control

0-100% set by software

Power supply

AC380V 50HZ 3phase

Weight

3000kgs/3500kgs/4500kgs/5500kgs
