Model

AD

Machining Area

1300x2500mm/1500X2500mm/1600x3200mm/2000x3000mm

Running Speed

25m/min

Spindle Motor

3.5kw air cooling spindle 380v/3ph 50hz(optional 220v/3ph 60hz)

Z Axis travel

150mm

Driving System

Stepper drive and motor

Guide Rail

TAIWAN guiding rail   （Y /X/Z =20mm)

Rack and pinion

Helical rack and pinion for X and Y axis transmission

Ball Screw

Taiwan TBI ball-screw for Z axis transmission

Cutter

∮6 ,∮12.7

Power Supply

AC380V/3PH50~60HZ (Optional 220v/3ph 60hz)

Inverter

4.0kw Inverter 380V 3phase (Optional 220v/3ph 60hz)

Weight

1000KGS

Control System

NC STUDIO /MACH3

Table

Aluminum working table

Oil supply system

Semi-automatic
